The robust solution for large surfaces and outdoor areas
- 160 Watt max
- High-performance LED fitting
- 16,000 lumens
- Highly polished reflector
- Powder-coated aluminum housing
- Dimmable (optional)
- IP65 protection class
- 4000 Kelvin
- Mounting bracket with rotation range of up to 180°
- Symmetrical beam angle: 120° x 120°
- Passive cooling
- Handmade in Germany
- Spare parts available even after many years
WALKS & OUTDOOR AREAS
perfectly illuminated
Based on experience and passion
The GALAXXY E is robust, waterproof to IP66 and quick to install. Thanks to its adjustable mounting bracket in combination with the high-gloss reflector, it directs the light exactly where it is needed.
A beam angle of 120° x 120° allows homogeneous and wide-area illumination. The passive cooling structure prevents the electronics from overheating, thus ensuring a long service life. The GALAXXY E is supplied with a color temperature of 4,000 K as standard. Other color temperatures are available on request.
High quality at low cost
The use of powerful LEDs ensures very high performance values with very low electricity costs. We only use high-quality components that are built in watertight in the luminaire housing.
GALAXXY E is the cost-effective replacement for older HQI spotlights, both outdoors for illuminating larger areas and for lighting aquaculture facilities or tropical plants.
Thanks to the powerful technology and the high-quality LED with output values of up to 200 lumens per watt, HQI spotlights with an output of up to 400 Watt and HPS spotlights with an output of up to 600 Watt can be replaced by a single GALAXXY- E. A replacement therefore pays for itself after just a few weeks
Technical details
| GALAXXY E | ||
| Dimensions | 400 x 420 x 80 mm | |
| Power | 160 Watt |
|
| Kelvin | 4.000 - optional 6.500 / 3.000 | |
| Current voltage / Input | 100-120V AC; 200-240 V AC - 50/60 Hz | |
| Weight | ca. 2,4 kg | |
| Control | DALI 0-10 V | |
| LED Channels | 1 | |
| LED Colors | 1 | |
| Lumes | 16.000 | |
| Ambient temperature | -25 - +50 Grad | |
| Protection class | IP 66 | |
| Light distribution / beam angle | 120° x 120° | |
